19mm Glass Cabinet Lock With Round Handle

5 0 Reviews

C810

Furniture Lock

This cabinet lock is suitable for 19mm diameter lock hole panel. ABS plastic housing and bright chrome cyclinder. Cylinder is 5 disc tumbler mechanism which can arrange up to 100 key code combination. The round design of the lock head higher than the panel can be as a handle using, which is convenient for opening and closing the door. The brass Key with nickel-plated which is single side milling that is easy to insert and rotate, and is not easy to break or damage.

Quantity:
Inquire Add to Basket

This glass door lock has a wide range of uses, such as its suitable for safe deposit boxes, moisture-proof boxes, furniture cabinets, monitoring boxes, lockers, network equipment, medical cabinets...etc.

Variety of cam in different sizes and styles to choose for assembly which also can be customized available. It is main used on glass door. Considering the assembly method and position of different use environments, you can freely choose to use hex nuts or clip to fix the lock on the door panel.

Features
  • ABS plastic housing, and zinc alloy die cast cylinder.
  • Black plastic housing and black E-coating cylinder standard; other colors housing and finishes cylinder available upon request.
  • 5 disc tumbler mechanism.
  • Brass keys, nickel plated.
  • Key may be withdrawn in one or both positions.
  • Various cam configurations and rotations available.
  • Cam is affixed by screw.
  • Hex nut or speed clip mounted.
  • Ideal for applications where a pull knob is needed with a cam lock.
  • All keyed alike or 25 combinations standard.
  • 100 combinations available.
Order Information
  • Refer to drawings, samples, etc. as the confirmation of product specification before placing the order.
  • After the order confirmed, the cancellation of the order or change the order contents can be allowed within 7 days from the date of receiving the order.
  • Delivery time: Estimated delivery time for standard product orders of 3,000pcs is within 45 days.
  • The minimum order quantity of the product is 500PCS/lot, and the order of "price based on quantity" also can be accepted (for details, please negotiate with the salesman)
  • Products can be customized according to customer requirements, as: Key combination, parts configuration, wire soldering process, surface treatment, key extraction position, adding anti-vibration, dust-proof, anti-static, and other functions.
  • UL approval and RoHS 2.0 (2011/65/EU) compliant.
  • The test report of the specified project can be provided according to the customer requested.
